SKU
NBS-2614
Extended Height
6.98 metres / 22.90′
Retracted Height
1.955 metres / 6.41′
Construction
Clear anodised aluminium telescopic sections with section stop guides and 3 x passivated D-locking clip
No. of Sections
4
Weight – Excluding D-clips
7.0 kg / 15.43 lbs
Wind Load Rating – Maximum
160 kph / 99 mph – with each section guy wire supported
Top Section Load Rating
12.0 kg / 26.46 lbs
Maximum Surface Area
0.2m²
Base Section Dimensions
Outside diameter: 61mm / 2.40″
2nd Section Dimensions
Outside diameter: 55mm / 2.16″
3rd Section Dimensions
Outside diameter: 50mm / 1.96″
Top Section Dimensions
Outside diameter: 45mm / 1.77″
Supplied Accessories
3 x gold passivated section locking D-clip
Suitable Accessories
order separate
– NBS-BS61 – flat ground/roof mount
– NBS-61WStand – drive-on under-wheel mount base
– NBS-61TBMount – tow-ball socket mount base
– NBS-AGR series – Anodised aluminium guy rings – suits sections
– NBS-GR series – 8PLT army green guy rope 5/10/15/20/25 metres
– NBS-GW series – 304 stainless steel guy wire 5/10/15/20/25 metres
Delivered Packaging
2.1 metre cardboard box with internal packing – 100% recyclable.
Stocked Status
In manufacture – please allow 15 working days
