The NBS-2452 is our 2-section 2.0m packed to 3.7m extended telescopic mast. The telescopic design of the NBS-2502 allows for reduced storage in a room or vehicle. Accessories for permanent or temporary installation/utilisation are available separately, please contact us for more information

Australian Owned & Manufactured Australian owned & manufactured for 50+ years.
In-house Support Experienced, knowledgeable in-house technical support
Customisation Available Customisation of finish, mounting and equipment fixings available
ISO Quality Certified QA Accredited ISO 9001 / ISO 14001 / ISO 45001


Have a question about a particular product on offer? Submit your enquiry below:

Your Name(Required)



Extended Height

3.7 metres / 12.13′

Retracted Height

2.0 metres / 6.56′


Clear anodised aluminium telescopic sections with section stop guides and 1 x passivated D-locking clip

No. of Sections


Weight – Excluding D-clips

2.0 kg / 4.40 lbs

Wind Load Rating – Maximum

160 kph / 99 mph – with each section guy wire supported

Top Section Load Rating

4.0 kg / 8.82 lbs

Maximum Surface Area


Base Section Dimensions

Outside diameter: 45mm / 1.77″

Top Section Dimensions

Outside diameter: 40mm / 1.57″

Supplied Accessories

1 x gold passivated section locking D-clip

Suitable Accessories
order separate

– NBS-BS45 – flat ground/roof mount
– NBS-45WStand – drive-on under-wheel mount base
– NBS-45TBMount – tow-ball socket mount base
– NBS-AGR series – Anodised aluminium guy rings – suits sections
– NBS-GR series – 8PLT army green guy rope 5/10/15/20/25 metres
– NBS-GW series – 304 stainless steel guy wire 5/10/15/20/25 metres

Delivered Packaging

2.1 metre cardboard box with internal packing – 100% recyclable.

Stocked Status

In-stock, ready for immediate delivery

NBS-2452 Technical Data Sheet
